• Supports 4K@60Hz, 4:4:4 chroma
• System can support over 1000 transmitters and receivers
• HDR10 and Dolby Vision compatible
• Dolby/DTS/PCM audio formats supported
• HDCP 2.2/1.4
• POE or can be powered using provided power supply
• Manual dip switch configurable for a truly IP-Less installation
• Easy GUI automatically detects new devices in the system
• Customizable labels and names of sources and displays
• Setup through the GUI can be done without a computer even being on site
• Analog and Digital audio breakouts on TX and RX
• Upscale to 4K@30Hz or downscale to 720p
• EDID preset/learning
• Video Wall mode supports configurations up to 25 displays
• OSD mode to display text, pictures, or logos on the screen
• Great for digital signage!
• Connects to the cloud to schedule events or to troubleshoot a situation remotely
• Able to be controlled with Alexa enabled products

Tech Support:

• • For EVO-IP tech support, please first complete the EVO-IP training here to become EVO-IP Certified
  • EVOIPTX1 is able to accept 4K@60Hz content as an input. Content is output from the EVOIPRX1 at 4K@30Hz
  • A managed switch is required. Click on the downloads tab for a list of recommended switches

Package Contents:

EVOIPTX1, EVOIPRX1, OR EVOIPCTL1 unit (each sold separately)
IR Transmitter (with EVOIPTX1 and EVOIPRX1)
IR Receiver (with EVOIPTX1 and EVOIPRX1)
5V Power Supply (optional, can be used as a redundant power with use of a POE switch)
Set of mounting ears/screws
Product Manual
